Insulated Panels
Clean Room Panels — HPL Surface
Non-porous High Pressure Laminate panels for pharmaceutical, healthcare and food processing. ISO 14644 Class 1–9 · GMP Grade A–D · Anti-bacterial coating option.
HPL Non-PorousISO 14644GMP A–DAnti-BacterialPIR/PUR/RW
ISO 5–9
Clean Room Classes
>4000
HPL Abrasion Cycles
GMP A–D
EU GMP Grades
10yr
Surface Warranty
HPL Technical Specifications
| HPL Composition | Kraft paper layers in phenolic resin (EN 438) |
| HPL Thickness | 0.8–1.2 mm |
| Abrasion Resistance | > 4,000 cycles (EN 438-2) |
| Chemical Resistance | Acids · alkalis · IPA · H₂O₂ (EN 438-2) |
| Anti-Bacterial Option | ISO 22196 rated surface coating |
| Core Options | PIR (Bs2d0) · PUR (E) · Rockwool (A1) |
| Panel Thickness | 50–150 mm |
| Joint System | T&G flush · coved R50/75/100 · cam-lock |
| Sealing | EPDM dual-lip + antimicrobial sealant |
| Standards | ISO 14644 · EU GMP Annex 1 · HACCP · FDA 21 CFR |
ISO 14644 Classification
| ISO 5 — GMP Grade A/B | ≤ 100,000 part./m³ — Aseptic filling |
| ISO 6 — GMP Grade B | ≤ 1,000,000 part./m³ — Background to A |
| ISO 7 — GMP Grade C | ≤ 10,000,000 part./m³ — Preparation |
| ISO 8 — GMP Grade D | ≤ 100,000,000 part./m³ — Support areas |
| ISO 9 | ≤ 1,000,000,000 part./m³ — Ambient |
Application Sectors
- Pharmaceutical manufacturing & sterile filling
- Hospital operating theatres & isolation rooms
- Food processing & packaging
- Electronics & semiconductor fabrication
- Biotech & cell therapy laboratories
