Insulated Panels

Wall Panels - PIR / PUR / Rockwool

Three core options: PIR (best thermal), PUR (cost-effective), Rockwool (A1 non-combustible + 42dB). 25-year PVDF warranty.

PIR λ=0.022Rockwool A142dB RwCE EN 13162

0.022

PIR λ W/mK

A1

Fire Class

42dB

Max Rw

25yr

PVDF Warranty

U-Values - PIR Wall (lambda=0.022)

Thickness	U-Value W/m²K	Application
50mm	0.43	Light partitions
80mm	0.29	Chilled +4°C
100mm	0.23	Cold storage
120mm	0.19	Frozen -18°C
150mm	0.15	Blast -35°C
200mm	0.11	-45°C ultra-low

U-Values - Rockwool Wall (lambda=0.040)

Thickness	U-Value W/m²K	Application
50mm	0.80	General insulation
75mm	0.55	Commercial
100mm	0.40	Hospitals, schools
120mm	0.34	High-rise A1 facade
150mm	0.27	Energy-efficient
200mm	0.20	Passive standard

Features & Applications

✓ Cold Storage Facilities -45°C to +10°C – blast freezers, chilled warehouses, distribution hubs	✓ Food Processing Plants HACCP-compliant surfaces, hygienic joints, cleanroom grade
✓ Pharmaceutical & Healthcare GMP-compliant, Rockwool A1 for fire-rated zones and hospitals	✓ Industrial Warehouses Wide-span cladding, fast installation, low lifecycle cost
✓ High-Rise & Commercial A1 Rockwool facade panels – EU CPR and UK Part B compliant	✓ EPC & Export Projects EXW to DDP worldwide – full container loads, BOQ support

Frequently Asked Questions

What is the difference between PIR and PUR wall panels?

PIR has thermal conductivity λ=0.022 W/mK – approximately 8% better than PUR (λ=0.024). PIR also has higher fire class (Bs2d0 vs E under EN 13501-1) and better stability above 80°C. PUR is the cost-effective choice for standard temperature applications.

When is Rockwool A1 mandatory instead of PIR/PUR?

Rockwool is the only sandwich panel core achieving A1 non-combustible classification under EN 13501-1. Mandatory for buildings over 11m, hospitals, schools, care homes and public assembly under EU CPR and UK Building Regulations Part B.

What thicknesses and widths are available?

40-200mm (50, 80, 100, 120, 150, 175, 200mm standard). Width: 1,000 or 1,140mm. Custom lengths cut to order. MOQ: one full container (800-1,200 m² depending on thickness).

What coatings and steel finishes are offered?

Polyester (25μm), PVDF (25-year warranty), PVC plastisol (200μm for aggressive environments), Stainless Steel 304/316 for pharma/food grade. All available in RAL colours.

What certifications do ARCOPAN wall panels carry?

CE marked under EN 13162 (Rockwool) and EN 13165 (PIR/PUR). ISO 9001:2015. HACCP documentation for food-contact applications. Full test reports and CE Declaration of Performance available on request.

Request a Technical Quote

Engineers respond within 24 hours. EXW to DDP worldwide. CE, ISO 9001:2015, HACCP.
