Warehouse
Warehouse Racking Systems — Cold Storage Rated
Selective pallet racking engineered for cold stores and blast freezers. −45°C impact tested, hot-dip galvanised 80μm, CE marked EN 15512. Up to 12,000 kg/bay.
−45°C Rated12,000 kg/Bay80μm Galv.CE EN 15512VNA Compatible
12t
Max Bay Load
−45°C
Impact Tested
80μm
Zinc Coat
6m
Max Upright
Load & Dimension Data
| Beam 1350mm | 1,500 kg/pair — Upright 3,000mm |
| Beam 1800mm | 2,500 kg/pair — Upright 4,000mm |
| Beam 2400mm | 4,000 kg/pair — Upright 5,000mm |
| Beam 2700mm | 6,000 kg/pair — Upright 6,000mm |
| Frame Load @ 3m upright | 4,000 kg |
| Frame Load @ 6m upright | 12,000 kg |
| Zinc Coating | Hot-dip galvanised 80μm (EN ISO 1461) |
| Impact Test Temp | −45°C Charpy V-notch |
| Beam Connector | Clip-in safety lock · tool-free adjust |
| Accessories | Column guards · aisle guides · wire decking |
| Standards | CE EN 15512 · EN 15620 · SEMA |
Request a Technical Quote
Our engineers respond within 24 hours. Upload drawings or BOQ for fast-track review. EXW to DDP worldwide — Warehouse Racking Systems.
